Facilities

The ER-C houses conventional and state-of-the-art electron microscopes, ranging from standard scanning electron microscopes to highly-specialised aberration corrected instruments offering sub-Å resolution imaging and spectroscopy, as well as quantitative measurements of electromagnetic field distributions using phase contrast techniques that include off-axis electron holography and 4D STEM.

TFS Spectra 300
The TFS Spectra 300 is a state-of-the-art FEG Scanning Transmission Electron Microscope (S/TEM) with a high-tension voltage range of 30 kV – 300 kV. Thanks to its specially designed enclosure it is not only possible to transfer information well below 1 Å resolution, it also allows the system to easily reach ultra-high resolution routinely in a noisier environment.

Facilities

FEI Titan G3 50-300 PICO

FEI Titan G2 60-300 HOLO

FEI Titan G2 80-200 ChemiSTEM

FEI Helios NanoLab 400S FIB-SEM

TFS Spectra 300

FEI Helios NanoLab 460F1 FIB-SEM

FEI Titan 80-300 STEM

FEI Tecnai G2 F20

FEI Titan 80-300 TEM
